Easymount 1600 SHW – EM-1600SHW

The Easymount 1600 Independently Heated Rollers laminator is designed to perform and built to last.

Description

The Easymount 1600 Independently Heated Rollers laminator is designed to perform and built to last. The advanced features allow you to laminate and mount.

Designed in-house by Vivid, the Easymount gives your business extra capacity by allowing you to offer your customers a complete service that you previously had to outsource.

Key Features

  • 6m/20ft a minute
  • Variable speed control
  • Foot pedal
  • Reverse mode
  • Multilingual control panel
  • 25mm / 1″ mounting thickness

Great for use in

  • Sign makers
  • Photographers

Ideally suited for

  • Posters, graphics and signs
  • Mounting prints to board
  • Pop-up displays
  • Applying vinyls, tapes and adhesive films
  • Outdoor signage
<!-- [et_pb_line_break_holder] -->
<!-- [et_pb_line_break_holder] -->

Specification

Laminating Speed (m/min / feet/min) 6 / 20
Max. Width (mm / inches) 1600 / 63
Mounting Thickness (mm / inches) 25 / 1
Roller Diameter (mm / inches) 130 / 5
Warm-up Time (mins) 15
Hot Roller Heater System Internal Infrared
Laminating Temperature Range (°C/°F) 0-130 / 32-266
Control Panel Digital
Pressure Adjustment Manual/Gauge
Film Core (mm / inches) 75 / 3
Power Supply AC (v, 50Hz) 220/240
Power Supply AC (v, 60Hz) 240
Power Supply Required (Amps)
Power Consumption (W) 5000
Dimensions – Width (mm / inches) 1990 / 78
Dimensions – Depth x Height (mm / inches) 650×1255 / 26×49
Gross Machine Weight (Kg / lbs) 205 / 452
